How to Build Real-time Chat App with Express, ReactJS, and Socket.IO?

Last Updated on March 3, 2021

I have always been very interested in learning how the live user interactions in real-time chat applications work? Such web applications always excite me to find the answer of how to build real-time chat app. To quench my thirst for knowledge, I started reading blogs and watching tutorials. After getting my hands on building a real-time chat app with Express, ReactJS, and Socket.IO, I decided to write a blog on it, as it was once said by Margaret Fuller, “If you have the knowledge, let others lit their candles in it.”

Overview

It might seem quite challenging when you read the topic – How to build a Chat App with Express, React, and Socket.io? This blog will surely take care of that challenge, and I’ll try my best to make it as simple as possible. So, let’s take the challenge and move ahead with a positive quote I read somewhere –

“We don’t grow when things are easy. We grow when we face challenges.”

Before starting the coding part, I would like to give some preliminary information about What is Socket.IO? You can skip this part and head towards the coding section if you’re familiar with Socket.IO already.

What is Socket.IO? And How Does it Work?

Socket.IO was developed for real time applications that can communicate and develop live user-interaction. As the documentation of Socket.IO states –

Socket.IO is a library that enables real-time, bidirectional, and event-based communication between the browser and the server.

With the help of Engine.IO, Socket.IO establishes the connection and permits bidirectional communication between client and server. The bidirectional communication takes place only when the client and server both have Socket.IO integrated. It transfers data in various forms, but the most likely in JSON format.

Socket.IO transfers data from the client of the particular server to the server, and then that server transmits it to other clients. This is how the transfer of information takes place.

I hope you now have a better understanding of Socket.IO. You can visit its documentation to start your Socket.IO tutorial. Finally, it’s time to build your own real time chat app.

How to Build a Real-time Chat App with Express, ReactJS, and Socket.IO?

I assume that you have Node.js V10 or higher version installed on your system. If not, then click here to install.

Starting with the basics

I’m creating here the main folder and then initiating it using NPM-

mkdir chat-app
cd chat-app

npm init

Setting up Express Server and Socket.IO

Once you click enter for all the options, install the Express library and Socket.IO for handling socket connections.

npm install --save express socket.io

After installing the Express and Socket.IO library, we will create a file to implement our new application’s logic.

touch server.js

Now we will write the express server code in the server.js file. Open your real-time chat-app and start editing it.

//server.js
let express = require('express')
let http = require('http')
let socket_IO = require('socket.io')

const PORT = 8001
let app = express()
let server = http.Server(app)
let io = socketIO(server)

io.on('connection', (socket) => {
  console.log('User is connected sucessfully')

  socket.on('disconnect', () => {
    console.log('Sorry! User is unfortunately disconnected')
  })
})

server.listen(PORT, () => {
   console.log(`Running on port ${port}.`);
});

Now, by running the below-mentioned command, ensure the code is working as expected.

node server.js

Your console should display – Running on port 8001.

Close the server using ctrl+c

On hitting the URL – http:// localhost: 8001, you won’t see anything as we still need to work on our front-end. So far, we are a bit done with the socket listener in our sever.js file.

Now let’s move on to my favorite part of building the real time chat application, i.e., front-end.

Front-end part: React Component

We will be using create-react-app for it, some also prefer to configure Webpack, but that’s up to you. If you don’t have create-react-app installed on your system, use the below command-

npm i create-react-app

Now let’s create our React application –

create-react-app chat-app-client
cd chat-app-client

You can remove unwanted files like – favicon.ico and logo.svg from your file structure.

Now, as we know, Socket.IO uses Engines.IO, due to which we need to install Socket.IO at both client and server sides. So, it’s time to install socket.io-client

npm i socket.io-client

Client-Server Connection

This section will see how to connect the client with the server and enable communication in real time chat application using Socket.IO.

import React from 'react';
import socketClient from 'socket.io-client';
const SERVER = "http:// 127.0.0.1:8001";
function ChatApp() {
 let socket_io = socketClient(SERVER);
   return (
      < div >
        < p >Just checking if this is working!< /p >
      < /div >
    );
}
export default ChatApp;

Make these necessary changes in your server.js file so that the client listens to all the emitted events from the backend.

//server.js

let express = require('express')
let http = require('http')
let socketIO = require('socket.io')

const PORT = 8001
let app = express()
let server = http.Server(app)
let io = socketIO(server)

const STATIC = [‘global_notif, global_chats’];

io.on(“connection”, (socket_io) => {
  console.log('User is connected successfully');
  socket_io.emit(“connection”, null);

  socket_io.on(“disconnect”, () => {
    console.log('Sorry! User is unfortunately disconnected');
  })
})

server.listen(PORT, () => {
   console.log(`Running on port ${port}.`);
});

Due to the function socket_io_emit, events can be emitted to the front end from the socket connection. Keep in mind that this transmission of data will be possible only with recently connected clients.

Now, the web socket connection is developed, so let’s proceed to build Chat.

How to Build Chat application?

We will have a folder named Chat, which will consist of our Channel’s components and the main Component of Chat. I won’t be adding CSS files for designing; instead, I’ll focus on the logic and components.

//Main_Chat.js

import React, { Component } from 'react';
import { Channels } from './Channels';

export class Main_Chat extends Component {
state = {
    all_channels: [
        { id: 10, name: 'John', members: 20}
      ]
    }
  render() {
     return (
        < div >
‍           < Channels all_channels={this.state.all_channels} / >
‍        < /div >
       );
    }
‍}

// Channels.js

import React, { Component } from 'react';

export class Channels extends Component {
   render() {
     let channel_list = `Sorry, No channels available`;
       if (this.props.all_channels) {
          list = this.props.all_channels.map(c =>
          < p > {c.name} < /p >
       }
       return (
          < div >
             {channel_list}
‍          < /div >
        );
    }
‍}

So, we have two files here- Main_Chat.js and Channels.js. Main_Chat.js includes the Channels.js, which will display data related to the channel list using the prop all_channels. We are done with the Chat folder now, moving ahead to create a message folder for Message Panel. We will build two files in that folder, namely Main_Message.js and Messages.js.

//Main_Message.js

import React, { Component } from 'react';

export class Main_Message extends Component {
   render() {
      return (
          < div >
              < p >{this.props.senderName}< /p >
              < span >{this.props.text}< /span >
           < /div >
        )
    }
‍}

//Messages.js

import React, { Component } from 'react';
import { Main_Message } from './Main_Message';

export class Messages extends Component {
    render() {

        let msg_list =
No messages!
;
        if (this.props.channel.messages) {
    const { msgs } = this.props
            list = msgs.channel.messages.map(msg =>
              ) />
        }
        return (
            < >
              < p >{msg_list}< /p >
‍              < >
< input type="text" >
 < button >Send< /button >
‍ < />
            < />
         );
    }
}

So far, we had set up the real time chat app with Express, ReactJS, and Socket.IO; now, without further ado, let’s move on to develop logic.

Logical part: Sending and Receiving Messages

We are done with the simple interface, and I hope you’ve managed your designing too. Moving on to focus on the logic part of our real time chat application, i.e., how to send and receive the messages?

How to fetch the channels?

Add the following code into your server.js file for retrieving the current channel’s data –

// server.js

app.get('/getAllChannels', (request, response) => {
   request.json({
       all_channels: STATIC
   })
‍});

This was for the backend side, write the following for frontend –

// Main_Chat.js

componentDidMount() {
   this.loadAllChannels();
‍}
loadAllChannels = async () => {         fetch('http:// localhost:8001/getAllChannels').then(async response => {
       let all_data = await response.json();
           this.setState({ all_channels: all_data.channels });
   })
‍}

Now, there’s a need for some events to be emitted and listeners in real time chat app. Whenever a channel is being selected, it should call an event that will eventually be handled in the backend. Also, the front-end has to look after the event. The front-end should have the same events emitted by the back-end to capture it and vice-versa.

// Main_Chat.js

handleSelect = (channel_id) => {
       this.socketIO.emit('channel-join', channel_id)
   }
   render() {
    const { all_channels } = this.state;


return (
          < Channels all_channels={all_channels}   onChannelSelect={this.handleSelect} / >
       );
‍}

// server.js

io.on('connection', (socket_IO) => {
    console.log('User is connected successfully!');
    socket_IO.emit('connection', null);
    socket_IO.on('channel_join', channel_id => {
        console.log('channel join', channel_id);
        STATIC.forEach(i => {
            if (i.id === channel_id) {
                if (i.sockets.indexOf(socket_IO.id) == (-1)) {
                    i.sockets.push(socket_IO.id);
                    i.members++;
                    io.emit('channel', c);
                }
            } else {
               let channel_index =              i.sockets.indexOf(socket_IO.id);
                if (channel_index != (-1)) {
                    i.sockets.splice(channel_index, 1);
                    i.members--;
                    io.emit('channel', c);
                }
            }
        });

        return channel_id;
    })
});

How to send messages?

Heading towards our last section of the blog – How to Build a Real-time Chat App with Express, ReactJS, and Socket.IO? After establishing a stable WebSocket connection, it’s time to learn how to send messages over it. This section will store the message typed in the textbox and then send that message by clicking Send. Open your Main_Chat.js file and make the necessary changes.

setUpSocketIO = () => {

 let socketIO = socketClient(SERVER);
 socketIO.on('connection', () => {
const { channels } = this.state;
   if (channels) {
     this.handleSelect(channels.id);
   }
 });

 socketIO.on('channel', channel => {

   let all_channels = this.state.all_channels;
    all_channels.forEach(i => {
       if (i.id === channel.id) {
         i.members = i.members;
       }
 });

 this.setState({ all_channels });});

socketIO.on('message', msg => {
 let all_channels = this.state.all_channels
   all_channels.forEach(i => {
     if (i.id === msg.channel_id) {
       if (!i.messages) {
         i.messages = [msg];
       } else {
         i.messages.push(msg);
       }
     }
   });
   this.setState({ all_channels });
 });

 this.socketIO = socketIO;
}
onSendingMessage = (id, msg) => {
 this.socketIO.emit('send-message',
    { channel_id: id,
     text: msg,
     name: this.socketIO.id,
     id: Date.now()
    });
 }

render() {
const { all_channels } = this.state;
 return (
   < >
     < Channels all_channels={all_channels}      onChannelSelect={this.handleSelect}
      / >
     < Messages onSendMessage={this.onSendingMessage} channel={all_channel} / >
   < />
 );
‍}

So, this was for the front-end part. Implementation at the back-end is quite simpler than this; we just have to broadcast the messages.

socketIO.on('send-message', msg => {
   io.emit('message', msg);
‍})

This was all about how to build your own real time chat app with Express, ReactJS, and Socket.IO. I hope the purpose of landing on this blog has been satisfied. With the combination of ReactJs and Socket.IO, you can build brilliant real time chat applications.

Conclusion
